Solicitud
The cables are designed for digital communications where 120Ω impedance are required during copper interconnection. They are used as primary access for ISDN services inside buildings between network termination equipment and subscriber termination equipment (G703 E1/T1 systems 2.048 or 1.544 Mbps).
Normas
• ER.f5.101
Construcción
Conductores
Solid annealed bare copper sized 0.4/0.5mm as per ASTM B-3/class 1 of IEC 60228
Aislamiento
Solid polyethylene as per ASTM D 1248/IEC 60708
Pares trenzados
Insulated conductors are twisted into pairs with varying lays to minimize crosstalk
Cable Troncal Asamblea
The pairs are cabled together in layers of 12, 13 & 25 pair unit to form the cable core. Units are identified by colour coded binders
Envasado básico
One or more non-hygroscopic polyester tapes are helically or longitudinally laid with an overlap
Pantalla
Aluminium/Polyester tape is applied longitudinally with an overlap
Vaina
PVC or LSZH compound
Ripcord
Nylon ripcord may be placed parallel to the cores to facilitate sheath removal
Armadura(opcional)
Corrugated steel tape armour
Additional Outer Sheath
PVC (for NYY Cables); PE (for Armoured Cables); LSZH
Escurrir Wire
Solid tinned copper 0.5mm drain wire may be laid longitudinally under the screen
Propiedades eléctricas
Propiedades mecánicas y térmicas
Temperature range during operation (fixed state): -30°C – +70°C
Temperature range during installation (mobile state): -20°C – +50°C
Minimum bending radius: 10 x Overall Diameter
Código de colores
Standard colour code is per BT CW 110J given in Colour Code Chart
Dimensiones y peso
| Código de cable |
Número de pares |
Espesor nominal de la vaina
mm |
Diámetro nominal global
mm |
Peso nominal
kg/km |
| 120Ω Twinaxial cable |
| 0.4mm Conductor, 1.0mm Insulated Wire |
| TX101-2Y(St)Y1P04-ISDN-P |
1 |
0.3 |
3.0 |
10.5 |
| 0.5mm Conductor, 1.5mm Insulated Wire |
| TX101-2Y(St)Y1P05-ISDN-P |
1 |
0.7 |
4.5 |
18.0 |
| Multipair 120Ω cable |
| 0.5mm Conductor, 1.2mm Insulated Wire, PVC Sheathed Indoor Cable |
TP101-2Y(St)Y2P05-ISDN-P |
2 |
1.0 |
7.0 |
31 |
TP101-2Y(St)Y4P05-ISDN-P |
4 |
1.0 |
8.2 |
57 |
TP101-2Y(St)Y8P05-ISDN-P |
8 |
1.0 |
10.0 |
86 |
TP101-2Y(St)Y12P05-ISDN-P |
12 |
1.0 |
10.5 |
113 |
TP101-2Y(St)Y16P05-ISDN-P |
16 |
1.0 |
11.8 |
142 |
TP101-2Y(St)Y18P05-ISDN-P |
18 |
1.0 |
12.5 |
152 |
TP101-2Y(St)Y20P05-ISDN-P |
20 |
1.0 |
13.2 |
157 |
TP101-2Y(St)Y24P05-ISDN-P |
24 |
1.0 |
13.5 |
191 |
TP101-2Y(St)Y28P05-ISDN-P |
28 |
1.0 |
14.0 |
219 |
TP101-2Y(St)Y32P05-ISDN-P |
32 |
1.0 |
16.5 |
260 |
TP101-2Y(St)Y50P05-ISDN-P |
50 |
1.2 |
19.2 |
370 |
TP101-2Y(St)Y75P05-ISDN-P |
75 |
1.2 |
23.2 |
530 |
TP101-2Y(St)Y100P05-ISDN-P |
100 |
1.2 |
26.5 |
720 |
| 0.4mm Conductor, 1.0mm Insulated Wire, PVC Sheathed Indoor Cable |
| TP101-2Y(St)Y4P04-ISDN-P |
4 |
0.7 |
6.4 |
38 |
| 0.5mm Conductor, 1.2mm Insulated Wire, LSZH Sheathed Indoor Cable |
TP101-2Y(St)H8P05-ISDN-P |
8 |
1.0 |
10.0 |
87 |
TP101-2Y(St)H16P05-ISDN-P |
16 |
1.0 |
12.0 |
132 |
TP101-2Y(St)H32P05-ISDN-P |
32 |
1.0 |
16.0 |
260 |
| 0.5mm Conductor, 1.2mm Insulated Wire, PVC Double Sheathed (NYY) Outdoor Cable |
TP101-2Y(St)YY4P05-ISDN-P |
4 |
1.0+1.2 |
10.0 |
105 |
TP101-2Y(St)YY8P05-ISDN-P |
8 |
1.0+1.2 |
11.6 |
145 |
TP101-2Y(St)YY16P05-ISDN-P |
16 |
1.0+0.6 |
13.0 |
170 |
TP101-2Y(St)YY32P05-ISDN-P |
32 |
1.0+1.3 |
18.5 |
325 |
| 0.5mm Conductor, 1.2mm Insulated Wire, PVC Inner Sheathed, Corrugated Steel Armour, PE Sheathed, Outdoor Cable |
| TP101-2Y(St)Y(STA)2Y16P05-ISDN-P |
16 |
1.0+1.2 |
17.0 |
310 |
